Stranded Copper Cable is an essential product for any modern electrical or communication system. It is a versatile product that has many different applications ranging from power transmission and distribution to the formation of communication networks.
This product is mostly used in the construction industry, where it is used to make electrical circuits in commercial and residential buildings. It is perfect for running and distributing power to lighting systems, appliances, and different types of machinery. In addition, it is an essential component for phone lines, Ethernet cables, television coaxials, and many other communication systems.
Stranded Copper Cable is made of pure copper, which is a highly conductive material. This makes it an efficient conductor for transmitting electric currents, and it is more durable than most other conductive materials. Copper can also withstand higher temperatures than other metals commonly used in electrical wiring systems.
In terms of construction, the Stranded Copper Cable is made of multiple twisted copper wire conductors, each with a protective insulation layer. The twisted wire structure is flexible, which makes the cable easier to work with and install.
One significant advantage of Stranded Copper Cable is that it has high tensile strength. This means that it is strong enough to withstand heavy loads and tension resulting from the movement or vibration of machinery, people, and equipment in the vicinity of the cables. This strength is further enhanced by the insulation layer that protects the conductors. The insulation prevents the conductor from being damaged and ensures that the cable stays intact after installation.
In terms of size, Stranded Copper Cable comes in various sizes to accommodate different electrical and communication needs. Typically, stranded copper cables come in sizes ranging from 8 AWG to 4/0 AWG. However, it is essential to note that the size of the stranded copper cable's gauge is directly proportional to its carrying capacity. Therefore, it is essential to have a professional electrical or communication engineer determine the appropriate size of the cable to use depending on the power requirements.
The Stranded Copper Cable is easy to install and maintain. The installation process is straightforward, and the cable is flexible enough to be molded into different shapes and configurations. Its insulation layer also makes it easy to handle during installation.
Another significant advantage of stranded copper cables is that they are resistant to corrosion. Copper is naturally resistant to oxidation, which reduces the chance of the cable corroding over time. This resistance to corrosion enhances the lifespan of the cable, making it a cost-effective solution for electrical and communication needs.
In conclusion, Stranded Copper Cable is an essential product for any modern electrical or communication system. It is versatile, durable, efficient, and easy to use. With its high tensile strength, resistance to corrosion, and a range of sizes, this product is perfect for businesses in the construction, communication, and electrical industries. Get in touch with us today to learn more about our Stranded Copper Cable products, and we will be happy to provide you with a quote.
|
NAME |
Stranded copper cable |
|
MATERIAL |
copper |
|
SURFACE TREATMENT |
Bare copper or tinned plated |
|
SIZE |
As customer’s requirement |
|
DRAWING |
customized design is acceptable. |
|
ADVANTAGES |
Low eccentricity ratio uniform thickness |
|
FEATURES |
1)High precision oxygen free copper |
|
2)Environmental protection material flame retardant low smoke |
|
|
3)Advanced equipment quality assurance |
Twisting:The outer layer of copper brush wire should be twisted rightward,unless it is any other agreement,twisted way of adjacent layer should be against.and manufacturer have the right to confirm the twisted way.
TS,TSX
|
Nominal Cross Section (mm²) |
Calculated cross-sectional area (mm²) |
Construction |
Calculated Outside diameter (mm) |
DC resistance Ω/km |
Calculated weight Kg/km |
||
|
The number of total single wires |
No. of strands x No.of wires Nominal diameter of a single wire(mm） |
TS |
TSX |
||||
|
0.25 |
0.242 |
63 |
7 X 9/0.07 |
1.0 |
75.5 |
81.1 |
2.28 |
|
0.315 |
0.323 |
84 |
7 X 12/0.07 |
1.1 |
56.6 |
60.7 |
3.04 |
|
0.40 |
0.404 |
105 |
7 X 15/0.07 |
1.2 |
45.2 |
48.6 |
3.81 |
|
0.50 |
0.512 |
133 |
7 X 19/0.07 |
1.3 |
35.7 |
38.3 |
4.82 |
|
0.63 |
0.620 |
161 |
7 X 23/0.07 |
1.5 |
29.5 |
31.6 |
5.84 |
|
0.80 |
0.808 |
210 |
7 X 30/0.07 |
1.6 |
22.6 |
24.3 |
7.61 |
|
1.00 |
0.990 |
1 26 |
7 X 18/0.10 |
1.8 |
18.5 |
19.3 |
9.33 |
|
1.25 |
1.264 |
161 |
7x23/0.10 |
2.0 |
14.5 |
15.1 |
11.9 |
|
1.6 |
1.594 |
203 |
7x29/0.10 |
2.2 |
11.5 |
12.0 |
15.0 |
|
2.0 |
1.979 |
252 |
7x36/0.10 |
2.4 |
9.23 |
9.65 |
18.6 |
|
2.5 |
2.47 |
315 |
7x45/0.10 |
2.7 |
7.39 |
7.72 |
23.3 |
|
3.15 |
3.134 |
399 |
7x57/0.10 |
3.0 |
5.83 |
6.09 |
29.5 |
|
4.0 |
3.958 |
504 |
7x72/0.10 |
3.3 |
4.62 |
4.83 |
37.3 |
|
5.0 |
4.948 |
630 |
7x90/0.10 |
3.8 |
3.96 |
3.73 |
46.6 |
|
6.3 |
6.243 |
552 |
12x46/0.12 |
4.3 |
2.94 |
3.07 |
59.1 |
|
8 |
7.872 |
696 |
12X 58/0.12 |
4.8 |
2.33 |
2.44 |
74.5 |
|
10 |
10.04 |
888 |
12 X 74/0.12 |
5.3 |
1 .83 |
1.91 |
95.1 |
|
12.5 |
12.46 |
1102 |
19x 58/0.12 |
5.9 |
1 .48 |
1.55 |
118.5 |
|
16 |
15.90 |
1406 |
19x74/0.12 |
6.7 |
1 .16 |
1.21 |
151.2 |
TSR
|
Nominal Cross Section (mm²) |
Calculated cross-sectional area (mm²) |
Construction |
Calculated Outside diameter (mm) |
DC resistance |
Calculated weight Kg/km |
||
|
The number of total single wires |
Number of strands x No.of wires Nominal diameter of a single wire(mm) |
TS |
TSX |
||||
|
0.063 |
0.0628 |
32 |
32/0.05 |
0.5 |
288 |
0.586 |
|
|
0.08 |
0.0785 |
40 |
40/0.05 |
0.55 |
231 |
0.733 |
|
|
0.10 |
0.0982 |
50 |
50/0.05 |
0.6 |
184 |
0.917 |
|
|
0.125 |
0.124 |
63 |
63/0 05 |
0.65 |
146 |
1.16 |
|
|
0.16 |
0.165 |
84 |
7X12/0.05 |
0.7 |
111 |
1.55 |
|
|
0.20 |
0.206 |
105 |
7 X 15/0.05 |
0.8 |
88.7 |
1.92 |
|
|
0.25 |
0.247 |
126 |
7 X 18/0.05 |
1.0 |
74.0 |
2.33 |
|
|
0.315 |
0.316 |
160 |
7X 23/0.05 |
1.1 |
57.8 |
2.95 |
|
|
0.40 |
0.399 |
203 |
7 X 29/0.05 |
1.2 |
45.8 |
3.76 |
|
|
0.50 |
0.495 |
252 |
12 X 21/0.05 |
1.3 |
37.0 |
4.69 |
|
|
0.63 |
0.636 |
324 |
12 X 27/0.05 |
1.5 |
28.9 |
6.02 |
|
|
0.80 |
0.801 |
408 |
12 X 34/0.05 |
1.6 |
22.9 |
7.58 |
|
|
1.00 |
0.990 |
504 |
12 X 42/0.05 |
1.8 |
18.6 |
9.37 |
|
|
1.25 |
1.268 |
646 |
19 X 34/0.05 |
2.0 |
14.5 |
12.1 |
|
|
1.6 |
1.567 |
798 |
19 X 42/0.05 |
2.2 |
11.8 |
14.9 |
|
|
2.0 |
2.015 |
1026 |
19 X 54/0.05 |
2.4 |
9.16 |
19.2 |
|
|
2.5 |
2.500 |
1273 |
19x67/0.05 |
2.7 |
7.38 |
23.8 |
|
|
3.15 |
3.144 |
817 |
19 X 43/0.07 |
3.0 |
5.87 |
29.9 |
|
|
4.0 |
4.022 |
1045 |
19 X 55/0.07 |
3.3 |
4.59 |
38.3 |
|
|
5.0 |
1.927 |
1292 |
19 X 68/0.07 |
3.8 |
3.71 |
47.3 |
|
|
6.3 |
6.288 |
1634 |
19 X 86/0.07 |
4.3 |
2.93 |
59.8 |
|
Advantages: The soft connection products produced by the company are characterized by good softness, strong elasticity, stable appearance of silver (tin) plating and even plating, strong adhesion, high smoothness and corrosion resistance, long service life, small connection resistance, excess conductive function and superior mechanical function.
Household appliances, lighting lamps, electronic equipment,instrument equipment,electric products,automobile and other connecting line.
Packing: inside plastic/wooden reel or customized, outside carton or customized
Delivery time: depends on quantity, usually two to four weeks
Shipping: sea, air, railway, express
The manufacturing process of copper foil soft joint is pressure welding or brazing welding.
Pressure welding , that is to press the copper strips or aluminum strips together firstly then use the molecular diffusion.
With our dedicated inspection equipment, we will gladly provide you a report on each of your products. The quality of copper wires of ZHEJIANG YIPU METAL MANUFACTURING CO., LTD. is absolutely guaranteed. You can buy them safely.
● Our flexible copper stranded wires are used in a variety of applications, including automotive, aerospace, and construction.
● Innovative thinking brings new products and solutions, which enables us to successfully launch more new Stranded Copper Cable than our competitors every year.
● We provide professional and reliable services as both a supplier and manufacturer.
● We make our company an ideal garden for our employees to realize their values and our customers to get the best quality products and services.
● We are dedicated to ensuring customer satisfaction by providing the best possible products and services.
● Our leaders are significantly higher than their peers in the awareness of innovation and talent strategy.
● Our factory has a team of experts who are dedicated to providing the highest level of customer service and support.
● We uphold the concept of green environmental protection and healthy life, and always adhere to the tenet of "technology, innovation, service, and communication", which effectively enhances the reputation of Stranded Copper Cable.
● Our factory has a proven track record of delivering high-quality flexible copper stranded wires on time and on budget.
● prosperity of our company through mutual loyalty between the company and its employees, and between the company and its customers.
