Nickel Clad Copper Wire is a premium quality wire that has been specifically engineered to meet the diverse and demanding needs of the modern technology industry. With its unique design and cutting-edge features, this wire is ideal for use in a wide range of electronic devices and machinery, including mobile phones, laptops, cameras, and more.
One of the key features of our Nickel Clad Copper Wire is its exceptional durability and resistance to wear and tear. The nickel coating that covers the copper core provides a high level of abrasion resistance, ensuring that the wire remains in perfect condition even after prolonged use. This makes it an ideal choice for applications that require the wire to handle constant load and friction.
Another key advantage of this wire is its excellent electrical conductivity properties. The copper core ensures that the wire can sustain a high level of electric current, while the nickel coating provides superior conductivity, reducing resistance and energy loss. This makes our Nickel Clad Copper Wire ideal for use in high-performance devices where efficient energy transfer is critical.
In addition to its excellent electrical and mechanical properties, our Nickel Clad Copper Wire is also highly versatile, with unique features that make it suitable for a wide range of applications. These include its excellent corrosion resistance, which ensures that the wire will remain in perfect condition even when exposed to harsh environments or corrosive substances. Moreover, the wire is also highly flexible, making it easy to shape and solder, and ensuring that it can be used in devices with complex designs.
Our Nickel Clad Copper Wire comes in a range of sizes and specifications, making it suitable for use in everything from small electronic devices to heavy-duty machinery. Whether you are looking for a wire that can handle a high level of current, resist abrasion, or withstand harsh environments, our Nickel Clad Copper Wire has the perfect solution.
Overall, our Nickel Clad Copper Wire is an exceptional product that offers unparalleled performance and durability, making it the perfect choice for businesses looking to upgrade their electronic devices or machinery. Its superior electrical and mechanical properties, combined with its versatility and range of specifications, make it a must-have product for any modern technology manufacturer. Contact us today to learn more about our range of Nickel Clad Copper Wire products and how they can help your business succeed!
Nickel-plated copper wire is made by plating shackles on the copper core, which has excellent corrosion resistance and excellent mechanical properties. At the same time, nickel-plated copper wire can reduce the high frequency loss in high frequency applications.We can supply plated copper wire in diameters from 0.02 mm to 2. 60 mm, and a variety of insulating and self-adhesive paints are available.
|
1.copper wire GB/T3953 |
|
2.Nickel YB127 |
|
3.Nickel-plated copper wire GB11019-89 |
|
4.Grade 2 4 7 10 27 |
|
5.Nickel content％ 2 4 7 10 27 |
| Grade Ω.mm²/m, 20℃≤ |
|
2 0.017960 |
|
4 0.018342 |
|
7 0.018947 |
|
10 0.019592 |
|
27 0.024284 |
| Nominal diameter d mm Deviation mm |
|
0.050-0.250 +0.008 -0.003 |
|
>0.250-1.300 +3%d -1%d |
|
>1.300-2.000 +0.038 |
| Nominal diameter mm |
elongation(%)≥ |
||
|
2 4 7 10 Grade |
27 Grade |
||
|
0.050-0.100 |
12 |
6 |
|
|
>0.100-0.230 |
12 |
8 |
|
|
>0.230-0.500 |
16 |
12 |
|
|
>0.500-1.600 |
20 |
16 |
|
1. limited TV subscriber line and near household wire coaxial conductor;
2. computer LAN, access network cable, field conductor material;
3. core line of high temperature radio frequency cable;
4. high temperature electronic wire conductor material;
5. connectors for various electronic components; power transmission and overhead lines for telephone lines;
6. electrified railway, rail line catenary, overhead line;
7. the braided shielding wire for power cables; grounding rods for electric power industry; conductor materials for medical equipment and equipment.
Shipment:
The goods ship by sea,air and express.If you want ship by other way,please do not hesitate to contact us.
Packing:
7KG/10KG/20KG/30KG/50KG…… in plastic or wooden roll, carton or wooden cases or as per requirements.
